CORROSION RESISTANT
air or electric Drive
air or electric Drive
The APU SC10-5 & EPU Series frames are built using 304 stainless steel for increased corrosion resistance.
air or electric Drive
air or electric Drive
air or electric Drive
We offer bolt tensioners that can be operated using air or electricity. The pressure gauge comes glycerin filled.
PORTABLE
air or electric Drive
PERFORMANCE
Between 25 (air driven) & 35 KG (electric) these tabletop designs are available with optional handles and wheels for increased portability.
PERFORMANCE
air or electric Drive
PERFORMANCE
These easy to use plug'&'play systems come with a 4.5-5 liter tank and are available with ratios 195:1 to 440:1.
APU SC10-5-BT Series - Air driven bolt tensioner
EPU BT Series - electrically DRIVEN BOLT TENSIONER
EPU BT Series - electrically DRIVEN BOLT TENSIONER
- Ratio Range:
- 195:1 to 440:1
- Tank Size:
- 4.5 Liters (1.18 Gallons)
- Max Working Pressure:
- 1.365 to 3.080 Bar
- Volume Per Stroke:
- 2.26CC to 1CC
- Flow Rate:
- 1.15l/min to .45l/min
- Dimensions:
- L 45 x W 45 x H 43 CM
EPU BT Series - electrically DRIVEN BOLT TENSIONER
EPU BT Series - electrically DRIVEN BOLT TENSIONER
EPU BT Series - electrically DRIVEN BOLT TENSIONER
- Ratio Range:
- 237:1 to 365:1
- Tank Size:
- 5 Liters (1.32 Gallons)
- Max Working Pressure:
- 1.635 to 2.515 Bar
- Volume Per Stroke:
- 2.26CC to 1CC
- Flow Rate:
- .3l/min to .2l/min
- Dimensions:
- L 63 x W 42 x H 48 CM
